4. OSD Operation

F4: ADM

F4 is an administrator only function. It allows the administrator to configure

and control the overall operation of the OSD. To change a setting double-click

it, or use the up and down arrow keys to move the highlight bar to it then press

[Enter].

After you select an item, a submenu with further choices to select from appears.

Double-click an item, or move the highlight bar to it then press [Enter]. An

icon appears before the selected item so that you know which one it is. The

settings are explained in the following table:

(Continues on next page.)

Setting Function

SET USER

This function is used to set usernames and passwords for the

administrator and users:

1. Usernames and passwords for one administrator and four users

can be set.

2. After you select the administrator field or one of the user fields,

a screen that allows you to key in the username and password

appears. Usernames and passwords can be from 1 to 16

characters long and can consist of any combination of letters

and numbers (A–Z, 0–9) and some additional keys (* ( ) + : - , ?

. / space).

3. For each individual, key in the username and password, confirm

the password, then press [Enter].

4. To modify or delete a previous username and/or password, use

the backspace key to erase individual letters or numbers. Press

[Enter] when done.

Note: Usernames and passwords are not case sensitive.

Usernames are displayed in capital letters in the OSD.

SET

ACCESSIBLE

PORTS

This function allows the administrator to define user access to the

computers on the installation on a port-by-port basis.

For each user, select the target port; then press the [Spacebar] to

cycle through the choices: F (full access), V (view only), or blank.

Repeat until all access rights have been set, then press [Enter].

The default is F for all users on all ports.

Note:

 A blank setting means that no access rights are granted. The

port will not show up on the user's LIST on the main screen.

 The administrator always has full access to all ports.
