![Aten SN3101 [3/3] Specifi cation](/views2/1211468/page3/bg3.png)
Altusen™ Enterprise Solutions
3
ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
© Copyright 2014 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Printed 06/2014 V4.0
Specifi cation
Centralized access control
The SN3101 makes security policy enforcement smooth and easy. Administrators
can authenticate user logins and authorize individual user rights via RADIUS,
LDAP, LDAPS and Microsoft Active Directory servers.
Modbus Ethernet –to –
Serial support
The SN3101's support for Modbus Ethernet-to-serial data transmission provides a
bridge that seamlessly integrates Modbus devices (such as PLCs, DCSs, HMIs, etc.)
into your serial network.
Function SN3101
Connectors
Serial 1 x DB-9 Male (Black)
Network 1 x RJ-45 (Black)
Power
PWR1 1 x 2-pin Terminal Block (Green)
PWR2 1 x DC Jack (Black)
Switches Reset 1 x Semi-recessed Pushbutton
LEDs
Power 1 x Green
Link 1 x Green
10/100 Mbps 1 x Orange / Green
T x R x ( ACT ) 1 x Green
Power Input
PWR1 12-48V DC (2-pin Terminal Block)
PWR2 9-30V DC (Power Adapter Jack)
Power Adapter 100-240V AC; 50–60 Hz
Power Line Protection 4KV burst (EFT), EN61000-4-42KV surge, EN61000-4-4
Power Consumption 9V, 2.7W
Interfaces
Serial
Standards RS-232/422/485; Software selectable
Baud Rate 460Kbps
RS-232 Signals TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 Signals Tx+, Tx-, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-, GND
RS-485 Signals Data+, Data-, GND
Serial Protection 15 KV ESD Protection for the serial port
Parity None, Even, Odd, Mark, Space
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Flow Control None, XON/XOFF, RTS/CTS
Network
Standards 10/100BaseTX; Autosensing
Protection 1.5 KV Magnetic Isolation
Protocols
ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IP, TCP, UDP, NTP, PPP, RADIUS,
Telnet, SNMP, SNMP Trap, SMTP, SSH
Regulatory Approval FCC Class A, CE Class A, RoHS
Environment
Operating Temp. 0-60ºC
Storage Temp. -20-85ºC
Humidity 0-95% RH, Non-Condensing
Physical
Properties
Housing Metal
Weight 0.22 kg
Dimensions (L x W x H) 10.69 x 7.90 x 2.44 cm
