ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
© Copyright 2016 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Publish Date: 09/2016 V8.0
VanCryst™ Professional A/V Solutions
4/8-Port HDMI over Cat 5 Splitter
VS1804T / VS1808T
Specifi cations
Features
The VS1804T / VS1808T HDMI over Cat 5 Splitter designed to connect
one source to 4 or 8 displays over a long distance. Incorporating
suggested compatible receivers*, the VS1804T / VS1808T HDMI over
Cat 5 Splitter can be a complete solution ideal for any professional A/V
installation that requires multimedia content to be delivered to multiple
destinations located up to 60 m away from the source.
* Compatible Receiver Units:
VB802 HDMI Over Cat 5 Repeater
VE800AR HDMI Receiver
The VS1804T/VS1808T is perfect for a wide range of applications:
• In-store or tradeshow digital signage
• Information broadcasts at public locations (e.g. fl ight times at an
airport, weather and tide forecasts at beaches)
• Sporting events
• Theater and lecture rooms
• Classrooms and company training facilities
• One HDMI input to 4/8 HDMI outputs via single Cat 5e cables*
• Extends displays up to 60 m
• Supports HDMI (3D, Deep Color)
• Supports Dolby True HD and DTS HD Master Audio
• Offers local HDMI output
• HDMI and HDCP compatible
• Consumer Electronics Control (CEC) allows interconnected
HDMI devices to communicate and respond to one remote
control
• Features RS-232 serial port for command controls**
• Cascadable to three levels
• Supports superior video quality – HDTV resolutions of 480p,
720p, 1080i, and 1080p (1920 x 1080)
• EDID mode selection
• Rack-mountable
Note:
* If you need to use EDID Bypass and/or HDCP authentication, connect
another Cat 5e cable between the VS1804T/VS1808T and VE800AR.
** The VS1804T/VS1808T AP and GUI operation instructions can be
the ATEN website (www.aten.com)
Function VS1804T VS1808T
Connectors
HDMI In 1 x HDMI Type A Female (Black)
HDMI Out Local 1 x HDMI Type A Female (Black)
Line Out
(Cat 5)
TMDS 4 x RJ-45 Female 8 x RJ-45 Female
DDC 4 x RJ-45 Female 8 x RJ-45 Female
RS-232 1 x DB-9 Female (Black)
Power 1 x DC Jack
Switches
EDID Mode 1 x 8-Position Switch
EDID Learn Mode 1 x Pushbutton
LEDs
Power 1 (Green)
HDMI In 1 (Green)
HDMI Out 1 (Green)
EDID Learn 1 (Green / Red)
Line Out 4 (Green) 8 (Green)
Video 1080p @ 40 m; 1080i @ 60 m
Power Consumption DC 5.3 V, 8 W DC 5.3 V, 13 W
Environment
Operating Temp. 0˚ to 50° C
Storage Temp. -20˚ to 60° C
Humidity 0 - 80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 2.10 kg 2.15 kg
Dimensions
(L x W x H)
43.72 x 15.78 x 4.40 cm
Rack
Mountable
Resolution
1080p
HDMI
A/V In
A/V Out
HDMI
60
EDID
mode
VS1808T Rear (parent)
HDMI Out
HDMI
HDMI In
VS1808T Rear (child)
VE800AR
