Chapter 1

Introduction

Overview

The ATEN VanCryst VM1616T 16x16 Cat5 A/V Matrix Switch is a versatile

audio/video over Cat 5+ serial solution that offers an easy and affordable way

to route any of 16 audio/video sources to any of 16 displays plus one local

video output, in combination with an ATEN Video Extender system.

With sixteen Cat 5 A/V input ports, the VM1616T allows you to connect

sixteen source devices (via sixteen Video Extender transmitters) to sixteen

monitors, displays, or projectors (via sixteen Video Extender receivers) at the

same time. In addition to the sixteen Cat 5 connections, the unit is also enabled

with local audio/video outputs so that an extra monitor located in the same rack

as the VM1616T can function as a further receiver.

As a Matrix Switch, each input can be independently connected to any or all

outputs, and the audio and video inputs from each source device can also be

switched independently, giving you the ultimate in flexibility and control in

any multi-display audio/video installation.

While the A/V signal travels over Cat 5 cable, the VM1616T unit can be

controlled over a standard TCP/IP connection, and so it will seamlessly

integrate with your existing network infrastructure. It allows convenient

configuration and operation via an intuitive Graphical User Interface (GUI),

accessed via web browser, as well as locally via front panel pushbuttons and

LCD display. The VM1616T can also be accessed via a remote terminal

session using Telnet.

Furthermore, for complete system and install integration, serial control is

standard through the VM1616T’s built-in RS-232 and RS-485/422 ports that

allow the switch to be controlled through a high-end controller or PC. The

unit’s bi-directional RS-232 serial port also allows serial devices, such as

touchscreens and barcode scanners, to be included in the installation.

In combination with a compatible ATEN over Cat 5 Video Extender system,

the VM1616T can support distances of up to 300 meters at 1280 x 1024 video

resolution between the transmitter and receiver units. It supports higher

resolutions of up to 1920 x 1200 at shorter distances. The VM1616T is an ideal

solution for applications that require A/V + serial information from multiple

sources to be conveniently delivered to any of multiple destinations.
