- 6 -- 5 -

Uninstalling the 98 / ME Driver:

If you should ever need to unistall the driver files, simply do the

following:

1. Unplug the USB-Parallel cable from the PC.

2. Use the driver you download from our website.

3. Run the UNINST.EXE program.

4. Reboot the computer.

Printer Installation

If your printer has already been installed:

1. If the UC-1284B is plugged into the computer, unplug it

2. Plug the Centronics end of the UC-1284B into the printer;

then power the printer On

3. Plug the USB end of the UC-1284B into the computer

4. Open the My Computer folder; open the Printers folder

5. Right-click on your Printer icon; select Properties from the

menu; select the Details folder tab

Open the printer port listbox by clicking on the arrow.

 For Win 98 / Me, select LPT2: (ATEN UC-1284B).

 For Win 2000 / XP select Virtual printer port for USB.

If your printer has not been previously installed:

1. Follow steps 1-4, above.

2. Double Click on the Add Printer icon

3. When prompted, select the printer manufacturer and model

from the list provided by the Add Printer Wizard

4. When prompted for the printer port:

 For Win 98 / Me, select LPT2: (ATEN UC-1284B).

 For Win 2000 / XP/Vista/7 select Virtual printer port for

USB.

5. Follow the Wizard’s instructions to complete the installation,

and print a test page to ensure that there are no problems.

Specifications

Function Specification

Connectors USB Type A Plug

Printer C-36 Male

Cable Length 30 cm

Power Consumption 90mA (max.)

Power Mode Bus Powered

Operating Temperature 5 ~ 40 c

Storage Temperature -20 ~ 60 c

Humidity 0 ~ 80% RH, Non-condensing

Housing Plastic

Weight 110 g

Limited Warranty

IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE

PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE

OF THE PRODUCT, DISK, OR ITS DOCUMENTATION.

The direct vendor makes no warranty or representation, expressed, implied, or

statutory with respect to the contents or use of this documentation, and especially

disclaims its quality, performance, merchantability, or fitness for any particular

purpose.

The direct vendor also reserves the right to revise or update the device or

documentation without obligation to notify any individual or entity of such

revisions, or update. For further inquiries, please contact your direct vendor.

USER MANUAL

USB-Parallel Printer Cable

UC1284B
