H110M4-C3V/H110M4-C3D USER MANUAL
5
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1151 socket for Intel
®
Skylake processor
2. CPU_FAN 4-pin CPU cooling fan connector
3. DIMM1~2 240-pin DDR4 Module slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SATA1~4 Serial ATA 6Gb/s connectors
6. F_PANEL Front panel switch/LED header
7. USB3F Front panel USB 3.0 header
8. ME_UNLOCK ME unlock header
9. F_USB1~2 Front panel USB 2.0 headers
10. COM Onboard serial port header
11. F_AUDIO Front panel audio header
12. BZ Buzzer header
13. PCIEX1 PCI Express Gen2 x1 slot
14. CASE CASE open header
15. PCIEX16 PCI Express x16 slot Gen3 for graphics interface
16. SYS_FAN 4-pin system cooling fan connector
17. CLR_CMOS Clear CMOS jumper
18. ATX_12V 4-pin +12V power connector
