H110M4-C23/C2H/C21 USER MANUAL

Brief Introduction

Specifications

CPU

•Intel

H110 Chipset

Chipset

• Supported by Intel

H110 Express Chipset

- 4 x Serial ATA 6Gb/s devices

Storage

• LGA1151 socket for

Intel

Skylake processor

• Supports CPU up to 65W

Note: Please go to ECS website for the latest CPU support list.

• 1 x PS/2 mouse & PS/2 keyboard connector

• 2 x HDMI ports (or 1 x HDMI port or 0 x HDMI port)*

• 1 x D-sub port (VGA port)

• 2 x USB 2.0 ports

• 2 x USB 3.0 ports

• 1 x RJ45 LAN connector

• 1 x Audio 6-ch jacks (line-in, line-out, microphone)

Rear Panel I/O

LAN • Realtek RTL8111H Gigabit Lan

• Realtek ALC662-VD0-GR 6-CH High Definition audio CODEC

- Compliant with HD audio specification

Audio

Expansion

Slots

• 1 x PCI Express x16 Gen3 slot

• 1 x PCI Express x1 Gen2 slot

• Dual-channel DDR4 memory architecture

• 2 x 288-pin DDR4 LONG DIMM sockets support up to 32 GB

• Supports DDR4 2400 MHz DDR4 SDRAM

Memory

Note: Please go to ECS website for the latest Memory support list.

Note: *H110M4-C23 has two HDMI ports, H110M4-C2H has one HDMI

port, and H110M4-C21 has no HDMI port.

Internal I/O

Connectors &

Headers

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin ATX 12V Power connector

• 1 x 4-pin CPU_FAN connector

• 1 x 4-pin SYS_FAN connector

• 1 x USB 3.0 header supports additional two USB 3.0 ports

• 2 x USB 2.0 headers support additional four USB 2.0 ports

• 4 x SATA 6Gb/s connectors

• 1 x Front Panel audio header

• 1 x Front Panel switch/LED header

• 1 x COM header

• 1 x Clear CMOS jumper

• 1 x Buzzer header

• 1 x Case open header
