ECS Elitegroup RX480-A [11/86] Introducing the motherboard
![ECS Elitegroup RX480-A [11/86] Introducing the motherboard](/views2/1212439/page11/bgb.png)
5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
1 CPU Socket Socket 939 for AMD K8 processor
2 CPU_FAN CPU cooling fan connector
4 ATX_POWER Standard 24-pin ATX power connector
LABEL COMPONENT
8 IDE1 Primary IDE channel
3 DIMM1~4 184-pin DDR SDRAM slots
11 SATA1~4 Serial ATA connectors
5 CLR_CMOS Clear CMOS jumper
9 FDD Floppy diskette drive connector
7 IDE2 Secondary IDE channel
6 PWR_FAN* Power fan connector
10 PANEL1 Front panel switch/LED header
16 BIOS_WP BIOS protection jumper
13 USB3-4 Front Panel USB headers
22 ATX12V 4-pin +12V power connector
21 PCIEX16 PCI Express x16 graphics card slot
18 CD_IN1 Analog audio input connector
19 AUDIO2 Front panel audio header
17 SPDIFO2 SPDIF out header
14 PCI1~3 32-bit add-on card slots
“*” stands for optional components.
20 PCI-E1~2 PCI Express x1 slots
15 IR1* Infrared header
12 J1 Speaker header
23 SYS_FAN* System cooling fan connector
