Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket FM1 for AMD A series processors
2. SYS_FAN System cooling fan connector
3. CPU_FAN CPU cooling fan connector
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SPI_DEBUG SPI debug header-for factory use only
7. SATA1~6 Serial ATA 6.0 Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. SPDIFO SPDIF out header
10. CLR_CMOS Clear CMOS jumper
11. F_USB1
Front
p
anel USB 2.0 header
˄
with EZ Char
g
e function
˅
12. F_USB2 Front panel USB 2.0 header
13. USB3F Front panel USB 3.0 header
14. SPK Speaker header
15. LPT Onboard parallel port header
16. COM Onboard serial port header
17. CASE Case open header
18. PCI 32-bit add-on card slot
19. PCIE1~2 PCI Express x1 slots
20. PCIEX16 PCI Express slot for graphics interface
21. F_AUDIO Front panel audio header
22. ATX12V 4-pin +12V power connector
