Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for latest new Sandy Bridge high-end
desktop processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SYS_FAN System cooling fan connector
6. SATA5~6 SATA 6Gb/s connectors
7. SATA1~4 SATA 3Gb/s connectors
8. PWR_FAN Power fan connector
9. F_PANEL Front panel switch/LED header
10. SPI_DEBUG SPI debug header-for factory use only
11. F_USB2 Front panel USB 2.0 header (F_USB2 supports EZ Charger)
12. F_USB1 Front panel USB 2.0 header
13. CLR_CMOS Clear CMOS jumper
14. SPK Internal speaker header
15. COM Onboard serial port header
16. CASE CASE open header
17. ME_UNLOCK ME unlock header for factory use only
18. LPT Parallel port header
19. F_AUDIO Front panel audio header
20. SPDIFO SPDIF out header
21. PCI1~2 32-bit add-on card slots
22. PCIE1~2 PCI Express x1 slots
23. PCIEX16 PCI Express x16 slot for graphics interface
24. ATX12V 4-pin +12V power connector
1. CPU Socket
