Using BIOS
Trusted Computing
Use this item to show the information of trusted computing configuration.
Press <Esc> to return to the Advanced Menu page.
TPM State (Enabled)
Select Enabled to display the status of TPM support for this system. Please note that
a system reboot is needed before a change on the TPM state to take effect.
Current TPM Status Information
This feature displays the current status of the TPM items listed below.
TPM Support (Enabled)
This item enables or disables TPM(Trusted Platform Module) support for system
security and data integrity. If this option is set to Enabled, the following items will
display.
Pending TPM operation (None)
Use this item to schedule a TPM operation that is pending.
If the option “None”
is displayed, there is no pending TPM operation in the queue. Please note that a
system reboot is needed for any change on the feature to become effective.
TPM Enabled Status (Disabled)
This item indicates if TPM support is enabled or not in this system.
TPM Owner State (Unowned)
This feature lists the status of the TPM Owner.
TPM Active Status (Deactived)
This item indicates if TPM support is active or not in this system.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Select which graphics
controller to use as the
primary boot device.
TPM Configuration
