50
Using BIOS
CPU OverClocking Configuration
Scroll to this item to view the following screen:
CPU Ratio (30)
This item allows users to control non turbo CPU ratio.
CPU Frequency (100)
This item shows the information of the CPU frequency.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep
Technology).
Graphics Voltage(1/256) (0)
This item allows you to adjust the internal GFX voltage.
Graphics Core Ratio Limit (22)
This item allows you to control the internal GFX Turbo ratio
.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 30
Enhanced Intel SpeedStep Technology Enabled
Intel Graphics Configuration
Graphics Core Ratio Limit 22
Graphics Voltage(1/256) 0
Enhanced Intel SpeedStep
Technology
