Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
Smart Fan Function
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
System Smart Fan Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 180
SMART Fan start PWM TEMP(-) 30
Delta T +3
SMART Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (-) 23
CPU Fan Speed : 4500 RPM
System Fan Speed : 0 RPM
CPU Voltage : 1.176V
DIMM Voltage : 1.524V
VAXG Voltage 0.984V
IMC Voltage : 1.056V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -18
Smart Fan Function
PC Health Status
CPU/System Smart Fan Control (Enabled)
This item enables you to define the CPU/system by smartly adjusting the CPU/
system Fan. When it is set at certain temperature, the CPU/system Fan PWM value
will change accordingly.
