![ECS Elitegroup P67H2-A [51/104] Using bios](/img/pdf.png)
ECS Elitegroup P67H2-A [51/104] Using bios
![ECS Elitegroup P67H2-A [51/104] Using bios](/views2/1212517/page51/bg33.png)
43
Using BIOS
Azalia HD Audio
Enabled
Disabled
+/- : Value
Enter : Select
:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
F2:Previous Value
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. Copyright (C) 2010, American Megatrends, Inc.
ME Subsystem Help
Intel ME Subsytem Configuration
ME Version 7.0.0.1105
ME Subsystem [Enabled]
Main Advanced Chipset M.I.B X Boot Security Save & Exit
ME Subsystem
Enabled
Disabled
Restore AC Power Loss (Power Off)
This item specifies what state to go to when power is re-applied after a power failure
(G3 state).
Audio Configuration
This item shows the information of the audio configuration.
Azaia HD Audio (Enabled)
This item enables or disables Azaia HD audio.
ME Subsystem
Scroll to this item and press <Enter> to view the following screen.
Press <Esc> to return to the chipset menu page.
ME Version (7.0.0.1105)
This item shows the ME version.
ME Subsystem (Enabled)
This item allows you to enable or disable ME subsystem.
