ECS Elitegroup H67H2-M [8/78] Introducing the motherboard
![ECS Elitegroup H67H2-M [8/78] Introducing the motherboard](/views2/1212528/page8/bg8.png)
4
Introducing the Motherboard
• Intel H67 Chipset
• latest socket LGA1155 Intel
®
2
nd
Generation
Core
TM
i7, i5, i3,
Pentium & Celeron processors
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 Gen2 slot
• 2 x PCI Express slots
• 1 x PCI slot
• Supported by Intel H67 Express Chipset
-2 x Serial ATA 6.0 Gb/s Host Controllers
-3 x Serial ATA 3.0 Gb/s Host Controllers
-1 x eSATA
• Realtek ALC892 8-Ch HD audio
• 4 x USB 2.0 ports
• 2 x USB 3.0 ports (Compatible with USB 2.0)
• 1 x VGA port
• 1 x DVI port
• 1 x Display port
• 1 x CLR_CMOS button
• 1 x HDMI port
• 1 x eSATA port
• 2 x RJ45 LAN connectors
• 1 x Audio port (Line in, microphone in, 8-ch line out and
optical SPDIF out)
Chipset
Memory
Expansion
Slots
Storage
Giga LAN
CPU
Specifications
Rear Panel I/O
• Dual Realteck 8111E Gigabit Lan
Audio
• ITE IT8893 PCI Bridge supports one PCI slot expansion
• Etron USB 3.0 Controller supports two USB 3.0 ports at the
back panel (Compatible with USB 2.0)
Extra Chips
