Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
Socket AM3 for AMD Phenom
TM
II/Athlon
II/Sempron processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE connector
6.SYS_FAN System cooling fan connector
7. SPK Speaker header
8.SATA1~6 Serial ATA connectors
9.F_PANEL Front panel switch/LED header
10. CLR_CMOS Clear CMOS jumper
11. LPT Parallel port header
12. F_USB1~2 Front Panel USB headers
13.SPDIFO
SPDIF out header
14.CD_IN Analog audio input connector
15. F_AUDIO Front panel audio header
16. PCI1~2 32-bit add-on card slots
17. CASE
Chassis detect jumper
18. PCIEX1 PCI Express x1 slot
19. PCIEX16 PCI Express x16 slot for graphics interface
20. ATX12V
8-pin +12V power connector
1. CPU Socket
