Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
processor (socket AM2+)/AMD Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/Sempron
TM
processors
2. CPU_FAN CPU cooling fan connector
3. SYS_FAN System cooling fan connector
4. DDR2_1~2 240-pin DDR2 SDRAM slots
5. ATX_POWER Standard 24-Pin ATX Power connector
6. IDE Primary IDE connector
7. SATA1~6 Serial ATA connectors
8. F_PANEL Front Panel Switch/LED header
9. LPT Onboard parallel port header
10. SPK Speaker header
11. CLR_CMOS Clear CMOS jumper
12. USBPWR_F1 Front Panel USB Power Select Jumper
13. F_USB1~2 Front Panel USB headers
14. IR Infrared header
15. SPDIFO SPDIF out header
16. CD_IN Analog audio input connector
17. F_AUDIO Front Panel Audio header
18. PCI1~2 32-bit add-on card slots
19. PCIEX1 PCI Express x1 slot
20. PCIEX16 PCI Express x16 graphics card slot
21. USBPWR_R1 Rear Panel USB PS/2 Power Select Jumper
22. ATX12V 4-pin +12V power connector
