ACS acr38u-nd [6/7] Technical specifications

ACR38U-ND – Technical Specifications info@acs.com.hk

Version 1.01 www.acs.com.hk

Page 6 of 7

4.0. Technical Specifications

Universal Serial Bus Interface

Type ..............................................Micro USB (OTG) Full-speed, Five Lines: +5 V, GND, ID pin, D+ and D-

Power Source ................................From Micro USB

Speed ...........................................12 Mbps

Smart Card Interface

Standard .......................................ISO 7816 Class A, B and C (5 V, 3 V, 1.8 V), T=0 and T=1

Supply Current...............................Max. 50 mA

Smart Card Read/Write Speed .......Max. 344,086 BPS

Short Circuit Protection ..................+5 V/GND on all pins

CLK Frequency..............................4 MHz

Card Connector .............................Contact

Card Insertion Cycles .....................Min. 100,000

Physical Specifications

Dimensions ...................................58.0 mm (L) x 20.0 mm (W) x 13.7 mm (H)

Color .............................................Black

Weight ...........................................10 g

Built-in Peripheral

LED ...............................................1 LED, Green

Operating Conditions

Temperature ..................................0 C – 50 C

Humidity ........................................10% – 90%

MTBF ............................................500,000 hrs

Application Programming Interface

PC/SC

CT-API (through wrapper on top of PC/SC)

Certifications/Compliance

FIPS 201, TAA, EN60950/IEC60950, ISO 7816, CE, FCC, VCCI, PC/SC, CCID, EMV 2000 Level 1, RoHS,

REACH, USB Full Speed

Microsoft® WHQL for Windows® 2000, Windows® XP, Windows Vista®, Windows® 7, Windows® 8,

Windows® 8.1, Windows® Server 2003, Windows® Server 2008, Windows® Server 2008 R2,

Windows® Server 2012, Windows® Server 2012 R2
