Hyundai H-1541 Black/Orange [3/9] Bottom backlight
![Hyundai H-1541 Black/Orange [3/9] Bottom backlight](/views2/1021353/page3/bg3.png)
2 3
Instruction manual Instruction manual
durations the battery may become exhausted or
there may be some deviation in accuracy.
• When the battery is exhausted, it should
be removed from the set to prevent leakage.
If you do not wish to take advantage of the
battery back-up system, your set will work
normally without a battery. However, if
disconnected from the mains, the clock figures
will flash when the mains are re-connected and
you must re-set the clock.
AС operation
• The appliance is for household use only.
• Before the first connecting of the appliance
check that voltage indicated on the rating label
corresponds the mains voltage in your home.
• Insert the plug into the power supply.
• The set is now working as electronic clock.
General operations
Setting the clock and calendar
• Press and hold MODE button. Press it
repeatedly to cycle through time and calendar
settings in following order: Year => Month =>
Day => 12/24H mode => Current hours =>
Current minutes. The selected setting will blink.
• Press repeatedly TEMP/
button or
press and hold it to decrease the setting; press
repeatedly Y-M-D/
button or press and hold
it to increase the setting.
• In normal mode, press repeatedly Y-M-D/
button to switch the display between
current time, year and month and day. Each
indication will be on for 5 seconds, the the
display returns to initial mode.
Dimmer function
To adjust the brightness of the display, slide
DIMMER switch to HIGH or LOW position.
Bottom backlight
To switch on/off backlight of the unit bottom,
slide LIGHT switch to ON or OFF position.
Reset
To reset all settings of the unit to default
settings, press the RESET hole with a pointed
object (e.g., a ballpoint pen). This measure is
needed when you changed the batteries in the
unit or if the unit does not function correctly.
Daylight saving time
Press and hold Y-M-D/ button to
switch on or off the DST (Daylight Saving
Time) mode. This enables to observe 1-hour
difference between summer and winter time.
Thermometer
Press TEMP/ button to show the current
temperature. The temerature indicatoin will
be on for 5 seconds, the the display returns to
initial mode. Press and hold TEMP/ button
to switch between Celsius and Fahrenheit
temperature modes.
Line input
• You can connect the audio output of an
external device to this unit, to listen to the
sound of that device through the amplifier of
this unit.
• To connect an external audio device (eg.
MP3 player), please use a standard stereo
cable (not included) with 3.5 mm to 3.5 mm
plugs to connect the headphone out or audio
line-out of the external device to the Line input
socket of this unit.
Radio operation
Tuner operations
• Press button to turn the radio on or off.
• Press BAND button to switch between AM
and FM radio bands.
• Adjust the program by rotating TUNER
regulator.
• Use VOLUME regulator to adjust volume
level.
• To obtain better FM signal reception,
