Fubag IR 220 VRD [4/22] Technical pecifications s

2. Technical pecificationss

3. D

escription

This welding machine is designed to operate under input voltage from 150 to 240V.

In case input voltage is lower than 220V the welding current is lower as well This must be considered

when choosing welding parameters and electrode.

Portable DC Inverter Arc Welder is designed to be used with the advanced IGBT (Insulated Gate

Bipolar Tube) and rapid recovery diode as its main control and transfer components and assisted

with the specially developed control circuit, it has uniformly regulated welding current which enable

the welding power source to achieve the adaptability to the excellent welding procedures. It is quite

popular in welding the materials like low-carbon steel, stainless steel, high-intension steel, alloy

steel and cast iron.

The highlighted characteristics of Portable DC Inverter Arc Welder:

- Featured with small volume and light weight, it widely used in upholstering field, repairing field and

fieldwork;

- Applicable in downward welding in the vertical position and the long arc spray transfer welding by

way of cellulose electrode;

- Its unique electric arc performances may satisfy the need of different welding procedures.

This welding machine has the following features:

1. Hot Start. Welding current is automatically increased at the start of a weld that helps you to ignite

the arc quickly and start welding .

2. Arc Force. Temporary increase of welding current that prevents the electrode from sticking. This

makes drop transfer from the electrode rod clear and smooth.

3. Anti Sticking. Reduced welding current helps to remove electrode in case of sticking without

damaging the coating.

www.fubag.ru

Omperator's anual

- 3 -

The manufacturer reserves himself the right to make the manual's content or welder's function

change without any preliminary notification of the users.

Item IR 160 IR 180 IR 200 IR 200 VRD IR 220 IR 220 VRD

Rated Input Voltage, V 220 220 220 220 220 220

Electrical Source Frequency, Hz 50 50 50 50 50 50

Rated Input Current, A 29 34 39 39 41 41

Effective Input Current, A 11,2 15,2 17,4 17,4 18,6 18,6

Rated Input Capacity, KVA 6,6 7,7 8,8 8,8 9,0 9,0

No-load Voltage, V 65 65 79 17,5 (VRD ON) 80 17,5 (VRD ON)

Min. Output Current, A 20 30 30 30 30 30

Max. Output Current, A 160 180 200 200 220 220

Voltage at min current, V 20,8 21,2 21,2 21,2 21,2 21,2

Voltage at max current, V 26,4 27,2 28 28 28,8 28,8

Duty Cycle, % 40 40 40 40 40 40

Power Factor 0,92 0,92 0,92 0,92 0,92 0,92

Insulation Grade H

Case Protection Grade IP21S

Cooling Type Fan Cool

Case Size (LxWxH), mm 300х120х195 340х120х195

Net Weight, kg 3,8 4,64
