Fubag IN 203 [6/14] Aintenance m

5 ower supply.P

- This machine is delivered with a plugged on a 220 (50 ) socket with earth.

- Connect the earth clamp and electrode-holder cables in the quick-plugs. Respect the polarities

indicated on the electrode packaging.

- To start the equipment, turn on the potentiometer to the desired current position, the power

indicator lights then. Put the potentiometer on "O" for standby mode.

25A V Hz

6 lectrode welding.E

MMA odem

Apply the usual welding rules

Leave the machine connected to the supply after welding in order to let it cool down

Thermal protection: thermal protection indicator turns on and the cooling time is about 2 to 5

min according to external temperature.

Your machine is equipped with 3 specific functions to Inverters:

increases the current at the beginning of the welding. Hot start



increases the current in order to avoid the sticking when electrode enters in

melted metal.

allows you to easily withdraw your electrode without damaging it in case of

sticking.

Connect the earth clamp on the positive (+) pole.

Connect a torch with valve on the negative (-) pole.

Connect the pipe of the gas bottle and adjust the flow.

Adjust the w current.

Аrc force

Аnti-sticking

TIG mode

- elding

www.fubag.ru

Omperator's anual

- 5 -

7 aintenance.M

- Regularly blow the welding machine with the pressed air through the ventilation inlets

Refer all servicing to qualified personnel.

Disconnect the generator and wait until the ventilator stopped before working on the unit.

Inside the device, voltages and current are dangerous.
