Asus x541uv, 90nb0cg1-m02830 [31/114] Two finger gestures

Asus X541SA, 90NB0CH2-M05430 [31/114] Two finger gestures

Notebook PC E-Manual

Left-click Right-click

• Clickanapptoselectit.

• Double-clickanappto

launch it.

Click this button to open the right-

click menu.

NOTE: The areas inside the dotted line represent the locations of the left

mouse button and the right mouse button on the touchpad.

Two-nger gestures

Tap

Tap two ngers on the touchpad to simulate the right-click function.
