11
Operation
1 2
3 4 5
1. Playback info window - shows current
playback time, track number, volume level,
playback status (stop/play/pause) etc.
2. Address window - shows directory
address at which the currently played file is
found.
3. Directory window - shows the currently
selected directory.
4. Scroll bar - shows file location in the
directory.
5. Preview window - shows the selected
JPEG file thumbnail.
Use
/ buttons to select the directory you
want and press or ENTER button to enter it.
Select a file and press or ENTER button to
start its playback.
JPEG playback notes:
• While a file playback, press
button, 12
thumbnails will be shown on the screen.
• Press cursor buttons to select the desired
picture.
• Use cursor buttons to select SLIDE SHOW
item, then press or ENTER button to start
slide show.
• Use cursor buttons to select MENU item,
then press
or ENTER button to enter button
function menu.
The button function menu is as follows:
Password setup
PASSWORD SETUP PAGE
PASSWORD MODE
PASSWORD
Change the password. The initial factory
password is 1369. You can set your own
password. If you forget your own password,
you can use 1369 as general password.
Other functions
MP3/JPEG/MPEG4 background
MP3 - generally adopted standard of audio
compression, compressing audio data to 1/12
of their size. One CD disc mat store more than
600 minutes of music (170 songs). And the
quality of MP3 disc approximates to an audio
CD disc quality.
JPEG (Joint Photographic Expert Group) -
image compression algorithm, used all over the
world and providing high level of compression
of the source data. Any graphics editor may
edit images of this format and their size in 15-
20 times less then the original images.
MPEG4 - standard for transmitting audio and
video data via channels with low capacity. This
format is very popular since it made possible
to place full-length movies with good enough
resolution in one CD.
When a disc, a USB or a memory card
containing files of these formats is inserted,
following interface will be displayed:
