The following two items appear only when you set the HD Audio Controller item to

[Enabled].

Front Panel Type [HD Audio]

Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or

high‑denition audio depending on the audio standard that the front panel audio

module supports.

[HD] Sets the front panel audio connector (AAFP) mode to high denition

audio.

[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97

DVI Port Audio [Disabled]

Conguration options: [Enabled] [Disabled]

Depop [Enabled]

Conguration options: [Enabled] [Disabled]

SupremeFX LED Lighting [Still Mode]

Allows you to set the behavior of the model name LED. Conguration options: [Disabled] [Still

Mode] [Breathing Mode] [Flowing Mode]

M.2 and SATA6G_1 Conguration [Auto]

Conguration options: [Auto] [Manual]

The following item appears only when you set the M.2 / SATA6G_1 Conguration to

[Manual].

M.2 and SATA6G_1 SATA Mode Configuration [SATA6G_1]

M.2 shares SATA mode with SATA6G_1 port. Change this item before installing M.2

SATA devices.

[M.2] SATA mode will be switched to M.2. SATA6G_1 cannot use.

[SATA6G_1] SATA mode will be switched to SATA6G_1. M.2 can only support

PCIE devices.

Asmedia USB 3.1 Controller [Enabled]

[Enabled] Enables the onboard USB 3.0 controller.

[Disabled] Disables the controller.

Asmedia USB 3.1 Battery Charging Support [Disabled]

This item appears only when the Asmedia USB 3.0 Controller item is set to [Enabled].

[Enabled] Enables the Asmedia USB 3.0 battery charging function.

[Disabled] Disables this function.

RGB LED Lighting [On]

[On] The LEDs will always light up at the S0(Working), S3(Sleep), and S5(Soft

off) states, but not light up at the S4/S5 state when the ErP Ready item is

enabled.

[Off] The LEDs will not light up.
