7. MAINTENANCE

MAINTENANCE

5. Repeat the above procedure until clear solvent or water comes out

of the nozzle.

6. Turn off device.

7. Then completely empty the container. Always keep the container seal free of

coating material and check for damage.

8. Clean the outside of the spray gun and container with a cloth soaked in solvent

You should inspect the air filter in the motor blower to see if it

is excessively dirty. If it is dirty, follow the steps to replace it.

1. Turn off device. Move off the external filter cover on top of motor blower

with a tool (such as a flat screw driver).

2. Remove the dirty filters and replace with new ones.

A. No coating material

is coming out of the

nozzle

B.The coating material

drips from the nozzle

C. Spray too coarse

D. Spray jet

pulsates

E. Pattern runs

or sags

ascending pipe is blocked.

4.Material adjustment screw

turned too far to the left (-)

5.The ascending pipe is loose.

6.No pressure is built up in the

container.

1.Nozzle is loose

2.Nozzle is worn

3.Material build-up on air cap

and nozzle.

5.Air filter very dirty.

6.Not enough pressure built up

in container.

1.Material in container running

out

2.Air filter clogged

1.Applying too much material

1.Gun too far from spray object

2.Too much material applied

4.Turn to the right (+)

2.Decrease volume setting (-)

3.Decrease volume setting (-)

4.Clean

5.Change

6.Tighten container

1.Refill

2.Change

1.Adjust material flow or

increase movement of

spray gun

Spraying pressure 0,1-0,2 Bar

Delivery rate 350 g/min

Max. viscosity 40 DIN-s

Weight 2,9Kg
