ASUS Z97-PRO Series
4-5
Chapter 4
Launching AI Suite 3
Windows
®
7 OS
FromtheDesktop,clickortapStart > All Programs > ASUS > AI Suite 3 > AI Suite 3.
YoucanalsolaunchAISuiteinWindows
®
7byclickingortapping ontheNotication
area.
Windows
®
8 and Windows
®
8.1 OS
TolaunchAISuite3inWindows
®
8orWindows
®
8.1,taptheAISuite3
appontheStartScreen(orifyou’reusingamouse,clicktheAISuite3
appontheStartScreen).
Windows
®
8 and Windows
®
8.1 OS
1. PlacetheSupportDVDintotheopticaldrivethenfollowonscreeninstructions.
2. FromtheASUS motherboard support DVDmainmenu,selecttheUtilitiestaband
clickortapAI Suite 3.
3. Followthesucceedingonscreeninstructions.
IftheASUS motherboard support DVDmainmenudidnotappear,trythefollowing:
a. Gotothe Start ScreenthenclickortaptheDesktopapp.
b. OnthelowerleftcorneroftheDesktop,clickortapFile Explorer then
selectyourDVDdriveandtapordouble-clickortaptheSetupapplication.
