ENGLISH
11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
PRESET EQ DRIVE EQ
/
TOP40
/
POWERFUL
/
ROCK
/
POPS
/
EASY
/
JAZZ
/
NATURAL
/
USER
:Selects a preset equalizer suitable to the music genre. (Select
[USER]
to use the settings made in
[EQ PRO]
.)
[DRIVE EQ]
is a preset equalizer that reduces noise outside the car or
running noise of the tyres.
BASS BOOST LEVEL1
/
LEVEL2
/
LEVEL3
or
LV1
/
LV2
/
LV3
:Selects your preferred
bass boost level.;
OFF
:Cancels.
LOUDNESS LEVEL1
/
LEVEL2
or
LV1
/
LV2
:Selects your preferred low and high
frequencies boost to produce a well-balanced sound at a low volume
level.;
OFF
:Cancels.
SUBWOOFER SET
*
ON
:Turns on the subwoofer output.;
OFF
:Cancels.
LPF SUBWOOFER
*
THROUGH
:All signals are sent to the subwoofer.;
85HZ
/
120HZ
/
160HZ
:Audio signals with frequencies lower than
85Hz/120Hz/160Hz are sent to the subwoofer.
SUB-W PHASE
*
REVERSE
(180°)/
NORMAL
(0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum
performance. (Selectable only if a setting other than
[THROUGH]
is
selected for
[LPF SUBWOOFER]
.)
FADER R15
to
F15
(
0
):Adjusts the rear and front speaker output balance.
BALANCE L15
to
R15
(
0
):Adjusts the left and right speaker output balance.
VOLUME OFFSET
For AUX:
–8
to
+8
(
0
) ; For other sources:
–8
to
0
:Preset the initial
volume level of each source. (Before adjustment, select the source you
want to adjust.)
SOUND RECNSTR
(Sound reconstruction)
ON
:Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost
in audio data compression.;
OFF
:Cancels.
•
[SUB-W LEVEL]
/
[SUBWOOFER SET]
/
[LPF SUBWOOFER]
/
[SUB-W PHASE]
is
selectable only if
[SWITCH PREOUT]
is set to
[SUBWOOFER]
or
[SUB-W]
.
( 4)
•
[SUB-W LEVEL]
/
[LPF SUBWOOFER]
/
[SUB-W PHASE]
is selectable only if
[SUBWOOFER SET]
is set to
[ON]
.
* Except for
AUDIO SETTINGS
Set the dimmer
Press and hold DISP (DIMMER) to turn on or off the dimmer.
• If you have set
[DIMMER TIME] ( 12)
, it will be canceled once you press
and hold this button.
Other settings
1
Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to select an item
( 12)
, then press the knob.
3 Repeat step 2 until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press and hold to exit.
To return to the previous setting item, press
.
DISPLAY SETTINGS
/ /
/ /
JS_KWD_KDC_210UI_ENE2N_EN_2.indd 11JS_KWD_KDC_210UI_ENE2N_EN_2.indd 11 29-Jul-16 3:56:35 PM29-Jul-16 3:56:35 PM
