Cisco ASA 5505 Adaptive Security Appliance Hardware Installation Guide
OL-18362-01
About This Guide
• Blank Faceplates and Cover Panels Warning, page viii
• Product Disposal Warning, page viii
• Short-Circuit Protection Warning, page ix
• Compliance with Local and National Electrical Codes Warning, page ix
• DC Power Connection Warning, page ix
• AC Power Disconnection Warning, page ix
• TN Power Warning, page ix
• 48 VDC Power System, page ix
• Multiple Power Cord, page ix
• Circuit Breaker (15A) Warning, page ix
• Grounded Equipment Warning, page x
• Safety Cover Requirement, page x
• Faceplates and Cover Panel Requirement, page x
Power Supply Disconnection Warning
Warning
Before working on a chassis or working near power supplies, unplug the power cord on AC units;
disconnect the power at the circuit breaker on DC units.
Statement 12
Jewelry Removal Warning
Warning
Before working on equipment that is connected to power lines, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat up when connected to power and ground and can
cause serious burns or weld the metal object to the terminals.
Statement 43
Wrist Strap Warning
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
Statement 94
Work During Lightning Activity Warning
Warning
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Statement
1001
Installation Instructions Warning
Warning
Read the installation instructions before connecting the system to the power source.
Statement 1004
