English
Adapter for chuck DWT PLUS • The power tool is supplied properly lubricated and
ready for use.
• DWT PLUS adapter 16 and screw 15 enable using
• A new power tool needs some time for its parts to
gear rim chuck 17 or keyless chuck 18.
run in before a full load operation. The run-in period
• Never use DWT PLUS adapter 16 in the impact
duration is about 5 hours of operation.
drilling or chiselling operation modes.
• The gear lubrications require a short time to get
• Drills that don't belong to the DWT PLUS system are
warm. Depending on the ambient temperature this
not allowed for the percussion drilling.
period of time can alter within the range of
approximately 15 s (at ambient temperature of 32°С)
Mounting / dismounting of the gear rim chuck or
up to 2 minutes (at ambient temperature of 0°С).
keyless chuck (see fig. 5-6)
Switching the power
• Screw the gear rim chuck 17 or keyless chuck 18
tool on / off
onto the DWT PLUS adapter 16 and lock it in with
the screw 15 (see fig.5).
Short-term switching on / off
• Install the DWT PLUS adapter 16 into the chuck 1
(DWT PLUS), repeating the same steps as when
mounting the borer (chisel) see fig. 6.
To switch on, press and hold on / off switch 12, to switch
• When dismantling, repeat the steps described above
off - release it.
in the reverse order.
Long-term switching on / off
Attention: keep in mind that in the
process of mounting / dismounting of the
Switching on:
gear rim chuck 17 or keyless chuck 18 the
Push on / off switch 12 and lock it in the position with
screw 15 has a left-hand thread.
locking button for on / off switch 13.
Switching off:
Mounting / replacement of accessories
Push and release on / off switch 12.
With long-term use the drill bit may
Design features
become very warm; use gloves to remove
of the power tool
it.
Power indicator
Gear rim chuck (see fig. 7)
[SBH08-26 T]
• Release the cams grip with clamping wrench 19, then
rotate the quill of gear rim chuck 17 counter-clockwise
Power indicator 14 is on when the power tool is
with your hand (see fig. 7) until the cams move apart at
connected to the mains and is ready to be switched
the distance allowing an accessory to be mounted /
on.
replaced.
• Mount / replace an accessory.
Function switch (see fig. 9-10)
• Rotate the quill of gear rim chuck 17 clockwise
with your hand in order to lock the accessory
mounted. Do not allow the accessory to become
Switching the operation modes shall be
distorted.
carried out only in the off mode of the
• Tighten the cams of gear rim chuck 17 with clamping
tool's motor.
wrench 19 applying a similar torque to each of the three
openings on the side surface of the chuck.
Function switch 8 is fitted with lock
button 7 that is used to fix the function
Keyless chuck (see fig. 8)
switch 8 in a set position. Rotate function
switch 8 while pressing button 7 in order
• Open the jaws of the keyless chuck 18 - hold its rear
to set a desired operating mode.
part with one hand and rotate its front part with the other
hand as it is shown in figure 8.
Function switch 8 is designed for the switching the
• Mount / replace the accessory.
following operation modes of the tool:
• Tighten the keyless chuck 18 without skewing the
accessory as it is shown in figure 8.
Drilling (set the function switch 8 in the position
indicated in figure 9.1 and 10.1) - non-percussion
Initial operation of the
drilling in wood, synthetics, metal.
power tools
Percussion drilling (set the function switch 8 in the
• Always use the correct supply voltage the power
supply voltage must match the information quoted on
position indicated in figure 9.2 and 10.2) - percussion
the power tool identification plate.
drilling in masonry, concrete, natural stone.
15
