Installing the SIM Card (Optional) | 11
Installing the SIM Card (Optional)
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 7. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 9. For additional safety best practices
information, see the Regulatory Compliance Homepage at dell.com/
regulatory_compliance.
NOTE: The SIM-card slot is available in your computer only if you ordered a
WWAN card at the time of purchase.
Procedure
1 Close the display and turn the computer over.
2 Insert a small pin or unfolded paper clip into the SIM-card slot pin-hole to release
the SIM-card holder.
3 Remove the SIM-card holder from the SIM-card slot.
