Multi-Graphics
Technology
Support for NVIDIA
®
Quad-GPU SLI
™
and 2-Way NVIDIA
®
SLI
™
technologies
Support for AMD Quad-GPU CrossFireX
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe x4/x2 SSD support)
- 1 x U.2 connector
- 2 x SATA Express connectors
- 6 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,RAID5,andRAID10
* Referto"1-8InternalConnectors,"fortheinstallationnoticesfortheU.2,M.2,SATA
Express, and SATA connectors.
USB Chipset+Intel
®
Thunderbolt
™
3 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 support
- 1 x USB 3.1 Type-A port (red) on the back panel
Chipset:
- 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x U.2 connector
1 x M.2 Socket 3 connector
2 x SATA Express connectors
6 x SATA 6Gb/s connectors
1 x CPU fan header
1 x water cooling fan/pump header (CPU_OPT_PUMP)
2 x system fan headers
1 x system fan/water cooling pump header (SYS_FAN2_PUMP)
1 x front panel header
1 x front panel audio header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x S/PDIF Out header
1 x Trusted Platform Module (TPM) header
1 x Thunderbolt
™
add-in card connector
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x Thunderbolt
™
3 connector
1 x USB 3.1 Type-A port (red)
1 x Mini-DisplayPort In port
1 x Mini-DisplayPort
1 x HDMI port
4 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1xRJ-45port
1 x optical S/PDIF Out connector
5 xaudiojacks(Center/SubwooferSpeaker Out, RearSpeaker Out, LineIn,
Line Out, Mic In)
- 7 -
