Hyundai h-swe3-30v-ui301 [12/56] Operation

12.

Electrical storage water heater

CAUTION!

During heating, water may begin to drip from the port of the pressure

safety valve. Water leakage cannot be avoided and shall not be prevented,

since blocking of the valve may result in rupture of the internal tank (in

case of equipment breakdown).

4. OPERATION

CAUTION!

Refer to «Water heater safe operation and installation rules»

1 – Power supply indicator

2 – Heating indicator

3 – Heating capacity regulation

4 – Thermostat knob

Open one of the demountable valves at outlet from the water heater and open the cold water

inlet valve. When water starts to freely ow out from the demountable valve, close it and insert

the plug of the power cord to the socket. When the water heater is used, the cold water inlet

valve shall be in open position. Power supply indicator lights up.

Choose necessary heating capacity using switches situated at the cover. Right switch actuates

low capacity (800 W), le switch actuates middle capacity (1200 W), two switches together

actuate high heating capacity (2000 W).

- « » - low capacity (800W),

- « » - middle capacity (1200W),

- « » - high capacity (2000W).

The water heating temperature in the water heater can be set in the range from +35°C to

+75°C. To increase the water heating temperature, rotate the thermostat knob clockwise. To

decrease the water heating temperature, rotate the thermostat knob counter-clockwise. The

water heater automatically maintains the set water temperature. When water temperature

in the water heater reaches the user set value, heating will be automatically stopped and the

heating indicator will extinguish. When water temperature in the water heater decreases below

the user set value, heating will be automatically activated and the heating indicator will light up

with bright pink color.
