ENGLISH
APPENDIX 35
COMPLIANT TIMING
M162E21
*
1
HDMI1, HDMI2, HDMI3 and DisplayPort input only.
*
2
HDMI1 and DisplayPort input only.
*
3
Recommended to use on PbP mode.
NOTE
Video Mode
Horizontal
Frequency
Vertical
Frequency
Dot Clock
VESA
VGA 640 × 480
31.469kHz 59.940Hz 25.175MHz
37.500kHz 75.000Hz 31.500MHz
37.861kHz 72.809Hz 31.500MHz
SVGA 800 × 600
35.156kHz 56.250Hz 36.000MHz
37.879kHz 60.317Hz 40.000MHz
46.875kHz 75.000Hz 49.500MHz
XGA 1024 × 768
48.363kHz 60.004Hz 65.000MHz
56.476kHz 70.069Hz 75.000MHz
60.023kHz 75.029Hz 78.750MHz
SXGA 1280 × 1024
63.981kHz 60.020Hz 108.000MHz
79.976kHz 75.025Hz 135.000MHz
WXGA+ 1440 × 900
55.935kHz 59.887Hz 106.500MHz
70.635kHz 74.984Hz 136.750MHz
WSXGA+ 1680 × 1050 65.290kHz 60.000Hz 146.250MHz
Full HD 1920 × 1080 66.590kHz 59.930Hz 138.500MHz
QWXGA
2048 × 1152 71.584kHz 60.000Hz 197.000MHz
WQHD 2560 × 1440 88.787kHz 59.951Hz 241.500MHz *
1
UHD 3840 × 2160
67.430kHz 29.970Hz 296.700MHz *
1
133.313kHz 59.997Hz 533.250MHz *
2
1920 × 2160 135.000kHz 60.000Hz 297.000MHz *
1,3
