ENGLISH
8 BEFORE YOU OPERATE THE MONITOR
CONTROLS AND CONNECTORS : ProLite B2282HV
<Front>
<Back>
Power Indicator
Blue: Normal operation
Orange: Power Management
Power Switch ( )
Menu / Select Button (MENU)
Scroll Up Button ( )
Scroll Down / ECO Mode Button ( / )
Exit Button (EXIT)
Auto Button (AUTO)
VGA(D-sub) mini 15pin Connector (D-SUB)
AC Connector
( : Alternating current)
( )
Keyhole for Security Lock
You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
Cable Holes
