AEG MP 8 220395 [9/22] Operating instructions

For the User

English

This water heater must be installed (water and electrical installation), commissioned and serviced

by approved service technicians in accordance with these instructions.

1. Operating Instructions

1.1 Description of the unit

The electronically controlled instantaneous water heater MP heats the water as it flows through the

appliance. The heating power is switched on automatically in the event of the minimum flow rate being

exceeded.

1.2 Key facts in brief

The MP is equipped with a safety temperature limiter (STL). After a cooling-off phase, the unit will

automatically switch the heating power back on.

The outlet temperature can be reduced by increasing the flow rate or by mixing in cold water. The hot

water output depends on the capacity of the unit, the cold water temperature, and the flow rate.

Table 1 shows the temperature rise of particular units as a function of the flow rate. If these volumes

are added to the cold water temperatures which prevail at the installation location, the particular hot

water temperature in each case can be obtained.

Example:

Cold-water inflow 10 °C

Flow rate 3 l/min

Temperature rise 32 °C

Hot-water outflow 42 °C

Temperature increase

Type Power* 2.6 l/min 3 l/min 4 l/min 6 l/min 8 l/min 10 l/min

MP 6 6.0 kW 33 °C 29 °C 22 °C 14 °C 11 °C 9 °C

MP 8 8.0 kW – 38 °C 29 °C 19 °C 14 °C 12 °C

* 220 V Volt supply

Table 1

1.3 Care

A damp cloth is all that is needed to look after the housing of the unit. Do not use any effervescent

cleaning agents or agents with a potentially solvent effect.

1.4 Maintenance

Maintenance work may only be carried out by a qualified installer. Page 19 provides a summary

of faults which you can deal with yourself.
