12 Using the Baby Monitor

3. Using the Baby Monitor

3.1 Setting up

• Place the Baby Unit in a convenient location (e.g. on a table) and point the

camera lens towards the area you want to monitor.

• Adjust the Baby Unit's head angle by rotating the camera up, down, left and

right until you are satisfied with the image on the Parent Unit.

NOTE

Do not place the Baby Unit within reach of a child or baby(s)! If there is

interference with the picture or sound, try moving the units to different locations,

and ensure they are not close to any other electrical equipment.

3.2 Night Vision Mode

The Baby Unit has 8 high-intensity infrared LEDs for picking up clear images in

the dark. When the built-in photo sensor on the top of the unit detects a low level

of ambient light, the LEDs will automatically activate and the screen on the

Parent Unit will display in black and white. The

N icon will be displayed at the top

of the screen.

3.3 Video ON/OFF

Press the VIDEO ON/OFF button V on the Parent Unit to turn the LCD display

on or off, but still leave the audio monitor on.

3.4 Talk Mode

Press and hold the T TALK button on the Parent Unit to talk to your baby through

the Baby Unit's loudspeaker. The

T icon will be displayed at the top of the LCD

screen.

3.5 Touchless Thermometer

The thermometer is designed to precisely measure the temperature of the

forehead (above eye brow and below hair line). Due to the unique body

physiology of each person, it is recommended that you take a person's

temperature at the same temple location to compare measurements. Please

contact your physician or seek medical attention if the fever is high or

prolonged.
