Set Up the Switch Configuration Utility

Plus switches are plug and play. You can install a configuration utility to select

2. Click Install ProSAFE Plus Utility and follow the prompts to install the

program.

The switch configuration utility is installed in the program directory of your

computer and a ProSAFE Plus Utility icon is placed on your desktop.

To configure the switch:

1. Double-click the ProSAFE Plus Utility icon.

The configuration home screen displays a list of plus switches that it discovers

on the local network.

2. Select the switch that you want to configure.

You are asked to enter the password for the switch.

Specifications

Specification Description

Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or 1000BASE-T

Network cable Category 5e (Cat 5e) or better Ethernet cable

Ports 5

Power 12V @ 1.0A DC input

Power consumption 2.6W maximum

Weight 0.252 kg (0.56 lb)

Dimensions

(W x D x H)

94 mm x 100 mm x 27 mm

Safety agency

approvals

CE mark, CB, CCC

Support

Thank you for selecting NETGEAR products.

use it to register your product at https://my.netgear.com.

You must register your product before you can use NETGEAR telephone support.

NETGEAR recommends registering your product through the NETGEAR website.

For product updates and web support, visit http://support.netgear.com.

NETGEAR recommends that you use only the official NETGEAR support resources.
