11En
English
* [PW SAVE] is canceled if the vehicle battery is disconnected and will need to be turned back on once
the battery is reconnected. When [PW SAVE] is off, depending on connection methods, the unit may
continue to draw power from the battery if your vehicle’s ignition does not have an ACC (accessory)
position.
AUTO PI
[ON], [OFF] Search for a different station with the same
pro
gramming, even if using a preset station.
AUX
[ON], [OFF] Set to [ON] when using an auxiliary device
c
onnected to the unit.
SPOTIFY
[ON], [OFF] Set to [ON] when using the Spotify function.
PW SAVE*
[ON], [OFF] Reduce the battery power consumption.
Turning on the source is the only operation
al
lowed when this function is on.
ANDROID WIRED
[MEMORY], [APP CONTROL] Select the appropriate connection method for an
A
ndroid device.
P.A P P A U TO O N
[ON], [OFF]
Select [ON] to automatically launch Pioneer ARC
APP when an Android device is connected to the
unit via AOA. (Not available when [MEMORY] is
selected in [ANDROID WIRED].)
USB AUTO
[ON], [OFF] Select [ON] to automatically switch to [USB]
so
urce when a USB device/iPod is connected to
the unit.
Select [OFF] when a USB device/iPod is being
connected to the unit just for charging.
Menu Item Description
ILLUMINATION settings
Menu Item Description
COLOUR
[KEY COLOUR], [DISP COLOUR],
[BOTH COLOUR]
Select colour for the keys/display of the unit from
12 preset colours, [SCAN] or [CUSTOM]*.
• [
SCAN]: Cycle through a variety of colours
automatically.
• [C
USTOM]*:
1 P
ress and hold the M.C. dial until the colour
setting display appears.
2 S
et the primary colour (R (red)/G (green)/B
(blue)) and brightness level ([0] to [60]).
You cannot select a level below 10 for all three
of
R (red), G (green), B (blue) at the same time.
You can also customise the preset colours. Select
o
ne of the preset colours, then press and hold
the M.C. dial until the colour setting display
appears.
* The CUSTOM setting is only available for [KEY
COLOUR] and [DISP COLOUR].
DIM SETTING
[SYNC ILLUMI], [SYNC CLOCK],
[MA
NUAL]
Change the display brightness.
BRIGHTNESS
[KEY], [DISP] Select the brightness for the keys/display of the
uni
t from [1] to [10].
The available setting ranges differ depending on
[D
IM SETTING].
ILLUMI FX
[ON], [OFF] The illumination effect can be seen when a CD is
in
serted/ejected.
The illumination effect will activate when the
A
CC power is turned on/off regardless of this
setting.
