Sigma ef 610 dg st eo-ettl2 для canon [2/2] Catch light panel

Sigma ef 610 dg st eo-ettl2 для canon [2/2] Catch light panel
Bounce Flash (exclusive downward by 7°) Downward by 7°
Without
Wide
Panel
Zoom coverage angle will be set to the
50mm position.
The flash coverage angle display will
show 50mm.
Zoom coverage angle will change
depend on the zoom length of lens.
At that time, the display of zoom
coverage angle will blink (2 times /
second).
With
Wide
Panel
The zoom coverage angle will be set to
17mm and both extremes of the zoom
coverage angle display (24mm & 105mm),
will blink (1 time / second)
Zoom coverage angle will be set to
17mm position and both extreme
values of the zoom coverage angle
display (24mm & 105mm) will be
blink (2 times / second).
■ The picture will receive the color from the reflecting surface. Please choose a white
surface for bouncing.
CLOSE-UP EXPOSURES
For bounce flash can be tilted 7° downward for close-ups. The Flash will be effective
only for the subjects 0.5 meter to 2 meters.
CATCH LIGHT PANEL
This flash is equipped with a built-in catch light panel, which can create a catch light in
the eyes of the subject when the bounce flash mode is activated. Slide out the wide
panel and catch light panel (fig.8-1), and then put wide panel back in its place (fig.8-2).
(Be careful to slide the panels out smoothly.)
■ To create a catch light effectively, tilt the flash head upward 90 degrees and take
pictures at a close distance (fig.9).
m
《表 1》《chart.1》《Tabelle 1》《Tableau 1》《tabel 1》《Tabla 1》 ft
17mm 24mm 28mm 35mm 50mm 70mm 105mm
1.4
1.5-16.4 2.1-24.3 2.2-25.0 2.3-25.7 2.9-32.9 3.3-37.1 3.9-43.6
4.9-53.8 6.9-79.7 7.2-82.0 7.5-84.3 9.5-107.9
10.8-121.7
12.8-14
3.0
2.0
1.0-11.5 1.5-17.0 1.5-17.5 1.6-18.0 2.0-23.0 2.3-26.0 2.7-30.5
3.3-37.7 4.9-55.8 4.9-57.4 5.2-59.1 6.6-75.5 7.5-85.3
8.9-100.
1
2.8
0.7-8.2 1.1-12.1 1.1-12.5 1.1-12.9 1.5-16.4 1.6-18.6 1.9-21.8
2.3-26.9 3.6-39.7 3.6-41.0 3.6-42.3 4.9-53.8 5.2-61.0 6.2-71.5
4.0
0.7-5.8 0.8-8.5 0.8-8.8 0.8-9.0 1.0-11.5 1.1-13.0 1.3-15.3
2.3-19.0 2.6-27.9 2.6-28.9 2.6-29.5 3.3-37.7 3.6-42.7 4.3-50.2
5.6
0.7-4.1 0.7-6.1 0.7-6.3 0.7-6.4 0.7-8.2 0.8-9.3 1.0-10.9
2.3-13.5 2.3-20.0 2.3-20.7 2.3-21.0 2.3-26.9 2.6-30.5 3.3-35.8
8.0
0.7-2.9 0.7-4.3 0.7-4.4 0.7-4.5 0.7-5.8 0.7-6.5 0.7-7.6
2.3-9.5 2.3-14.1 2.3-14.4 2.3-14.6 2.3-19.0 2.3-21.3 2.3-24.9
11.0
0.7-2.1 0.7-3.1 0.7-3.2 0.7-3.3 0.7-4.2 0.7-4.7 0.7-5.5
2.3-6.9 2.3-10.2 2.3-10.5 2.3-10.8 2.3-13.8 2.3-15.4 2.3-18.0
16.0
0.7-1.4 0.7-2.1 0.7-2.2 0.7-2.3 0.7-2.9 0.7-3.3 0.7-3.8
2.3-4.6 2.3-6.9 2.3-7.2 2.3-7.5 2.3-9.5 2.3-10.8 2.3-12.5
22.0
0.7-1.0 0.7-1.5 0.7-1.6 0.7-1.6 0.7-2.1 0.7-2.4 0.7-2.8
2.3-3.3 2.3-4.9 2.3-5.2 2.3-5.2 2.3-6.9 2.3-7.9 2.3-9.2
32.0
0.7-1.1 0.7-1.1 0.7-1.1 0.7-1.4 0.7-1.6 0.7-1.9
2.3-3.6 2.3-3.6 2.3-3.6 2.3-4.6 2.3-5.2 2.3-6.2
《表 2》《chart.2》《Tabelle 2》《Tableau 2》《tabel 2》《Tabla 2》
17mm 24mm 28mm 35mm 50mm 70mm
105m
m
MH 23.0 34.0 35.0 36.0 46.0 52.0 61.0
ML 5.8 8.5 8.8 9.0 11.5 13.0 15.3
《表 3》《chart.3》《Tabelle 3》《Tableau 3》《tabel 3》《Tabla 3》
ISO25 ISO50 ISO200 ISO400 ISO800 ISO1600
ISO3
200
X0.5 X0.71 X1.4 X2 X2.8 X4 X5.7
