SUPERSERVER 5018D-MTF/5018D-MTRF User's Manual
1-2 Motherboard Features
At the heart of the SuperServer 5018D-MTF/5018D-MTRF lies the X10SLM-F, a
single processor motherboard based on the Intel® C224 chipset. Below are the
main features of the X10SLM-F (see Figure 1-1 for a block diagram of the chipset).
Processors
The X10SLM-F supports a single Intel® Core™ i7/i5/i3 DT or Intel® Xeon® E3-1200
v3 or 4th Gen Core i3, Pentium and Celeron processors in an LGA1150 (H3) socket.
Please refer to the motherboard description pages on our website for a complete
listing of supported processors.
Memory
The X10SLM-F has four DIMM sockets that can support up to 32 GB of Unbuffered
ECC DDR3-1600/1333 memory. Please refer to Chapter 5 for installing memory.
Serial ATA
An on-chip SATA controller is integrated into the X10SLM-F to provide four SATA
3.0 (6 Gb/s) ports and two SATA 2.0 (3 Gb/s) ports.
I/O Ports
The rear I/O ports include one COM port, a VGA (monitor) port, four USB 2.0 ports,
and two gigabit Ethernet ports. A dedicated IPMI LAN port is also included.
