MEASUREMENT FOUNDATION

QUADRANT

4. Assembly

Inserting/Replacing the Battery

To open the battery lid 7 press on the latch 10 and fold the battery lid up. Insert the batteries. When inserting,

pay attention to the correct polarity according to the representation on the inside of the battery compartment.

Always replace all batteries at the same time. Only use batteries from one brand and with the identical

capacity.

Remove the batteries from the measuring tool when not using it for extended periods. When storing for

extended periods, the batteries can corrode and discharge themselves.

5. Operation

Switching On and Off

-

suring tool sends out the two laser lines at 0° and 90°.

Note: Do not point the laser beam at persons or animals and do not look into the laser beam yourself, not

even from a large distance. To switch off the measuring tool, push the On/Off switch 1 again.
