QUADRANT

MEASUREMENT FOUNDATION

6. Working Advice



fastening unevenly, the angle will not be precisely 90°. The measuring tool is not self-levelling. When lay-



alignment against walls.



being level. The reference point for alignment of tiles is the intersecting of the laser lines, directly in front of

the measuring tool. To project an angle, the measuring tool must be rotated at this intersecting point.

7. Positioning the Measuring Tool



T-edge 5 of the tool against a wall so that the 0° laser line runs parallel to the reference line (e.g. a wall).

Measure the clearance between laser line and reference line directly at the measuring tool and as far away

as possible from the measuring tool.



fasten the wall holder 11 to the wall, e.g. by placing the wall holder via an opening onto a screw that lightly

projects out of the wall. Then tighten the screw to secure the wall holder. Fasten the measuring tool with

the magnets 6 against the wall holder 11. Spirit levels 3 aid in precisely positioning the laser line against

the wall.
