GB
Translation of original user instructions
30
Petrol lawnmower
Blade coupling (optional)
Blade coupling
On Off
With the blade coupling, the mower blade can be engaged
or disengaged while the motor is running.
Engaging the blade coupling
1. Pull in the safety brake handle on the handlebar
and hold it (
17) - The brake handle does not
lock.
2. Push the coupling lever away from you (
21/1)
- The blade coupling is engaged.
Disengaging the blade coupling.
3. Release the safety brake handle (
25).
- The blade coupling is disengaged.
- The coupling lever moves to rest position ( 21/2).
Electrostart without primer/choke ( 15)
1. Set the throttle lever to the "START" position
(
15/1).
2. Pull in the safety brake handle on the handlebar and
hold it (
17) – the brake handle does not lock.
3. Turn the ignition key fully to the right in the ignition
lock (
19).
4. As soon as the motor starts running, release the
ignition key (it returns automatically to position "0").
5. According to the desired motor speed, set the
throttle lever to a position between
and
( 15/2).
Starting electrically (optional)
Electrostart with primer (
16)
1. Set the throttle lever to the "START" position
(
15/1).
2. Press the primer button 3 times at intervals of about
2 seconds (
16). If the temperature is below
10 °C, press the primer button 5 times.
3. Pull in the safety brake handle on the handlebar and
hold it (
17) – the brake handle does not lock.
4. Turn the ignition key fully to the right in the ignition
lock (
19).
5. As soon as the motor starts running, release the
ignition key (it returns automatically to position "0").
6. According to the desired motor speed, set the
throttle lever to a position between
and
( 15/2).
with remote throttle control, with primer ( 16)
Remote throttle
control
Start Stop
1. Set the throttle lever to position ( 20/1).
2. Press the primer button 3 times at intervals of about
2 seconds (
16). If the temperature is below
10 °C, press the primer button 5 times.
3. Pull in the safety brake handle on the handlebar and
hold it (
17) - the brake handle does not lock.
4. Pull out the starter cord sharply, then allow it to
slowly rewind (
18).
5. As soon as the motor starts running, set the throttle
lever for the desired motor rpm, at a position
between
and ( 20).
