Belkin F9K1102 [49/57] Troubleshooting support and warranty

TROUBLESHOOTING, SUPPORT, AND WARRANTY

I am having difficulty setting up Wired Equivalent

Privacy (WEP) security on my Router.

1. Log in to your Router. Visit “http://router/” or “http://192.168.2.1”

with your web browser. Click “Security” under the WiFi

heading. You should now be on the Security page.

2. Under Security Mode, select the “128-bit WEP” option.

3. You may type in a WEP key manually, or generate one from

a passphrase. Type a phrase in the “Passphrase” field and

click the “Generate” button. A WEP key is composed of 26

hexadecimal digits (0–9, A–F). For example, C3 03 0F AF

4B B2 C3 D4 4B C3 D4 EE 74 is a valid 128-bit WEP key.

4. Click “Save” to finish. Your wireless activity is now encrypted. Each

computer using your wireless network will need to use the new key.

Note: If you are configuring the Router over a wireless

connection, you will have to re-connect to the

Router after changing any security settings.

Note: Some older networking hardware supports

only 64-bit WEP encryption. If your older computers

cannot connect to your network, try 64-bit WEP.

A disk I plugged into the USB port is not

showing up on my computer.

1. Try unplugging and re-plugging the disk. Please check that

the USB connector is firmly plugged into the Router.

2. If your disk has an optional power supply, please use

it while the disk is attached to your Router.

3. The Router supports FAT16, FAT32-, or NTFS-formatted

disks. Disks in other formats will not appear in the

Finder (Mac OS X) or Windows Internet Explorer

A disk I plugged into the USB port is not coming

on or remains on only for a short time.

Some drives require more power than the Router’s USB

port provides. If your disk has an optional power supply,

please use it while the disk is attached to your Router.
