Connection
4
Connection
4
• All repairs and technical service should
be made by qualified specialist from service
centers.
All images provided herein are schematic
drawings and they may differ from the real
objects.
Connection
Before you start connection of external
devices, ensure that power of the unit is
switched off.
Audio/video output
Audio-video output is intended for
connecting an external display to this unit. For
connection use the included audio-video cable.
Audio/video input
The audio-video input is intended for
connecting external signal sources to this unit
by using the included AV cable.
Headphone jack
Connect your headphones to this unit by
using the headphone output. When headphone
is connected, the built-in speakers are mute.
Power connection
• For power supply from the electric mains
outlet 220 V, connect the included power
adaptor to the DC adaptor jack of this unit. Do
not use other DC adaptors.
• For power supply from the vehicle power
circuit, connect the car adaptor to the DC
adaptor jack of this unit. Do not use other car
adaptors.
• Power supply can be performed from
the built-in Li-Ion battery of this unit. The
battery power is enough for about 2 hours of
operation. The battery charge is performed
automatically when the unit is connected to
external power supply. During charging, the
green light of the power indicator is blinking.
TV antenna jack
Connect the included TV antenna to the TV
antenna jack for reception of TV signal.
