Demolition Hammer Н18/1500EV H10,5/1200EV

Rated voltage V~ 230

Rated current А 6.8 5.5

Rated frequency Hz 50

Rated power W 1500 1200

Impact rate bpm 1000… 1900 2700...3700

Nominal impact energy J 18 10,5

Chisel positions number of positions 12

Anti-vibration handle - Yes

Weight according to EPTA-Procedure 01/2003 kg 10.7 6.4

Protection class ll

Tool holder SDS Max

Acoustic pressure, Lpa dB(A) 89 87

Sound power level, Lwa dB(A) 100 98

Uncertainty K dB(A) 3 2.4

Vibration total values a

m/s

16 15

Uncertainty K m/s

1.5 1.5

TECHNICAL DATA

Read the operating instructions

Protection category II power tool; double

insulated

In accordance with essential applicable safety

standards of European directives

In accordance with essential applicable safety

standards of Russian Federation

Wear eye, ear, breathing protection

Follow very carefully the instructions in this manual,

save it and keep it close at hand, ready to carry out any

inspection of parts that may be necessary.

If the tool is used with care and normal maintenance is

carried out, it will work well for a long time.

The functions and use of the tool you have bought

shall be only those described in this manual. Any other

use of the tool is strictly forbidden.

ILLUSTRATIONS

The numbering of the product features refers to the

illustration of the machine on the graphics page.

1 Dust protection cap

2 Locking sleeve

3 Chisel adjustment ring

4 Auxiliary handle

5 Damper

6 On/Off switch

7 Principal hand grip

8 Thumbwheel for preselection of impact rate

9 Service indicator

10 Knurled nut for auxiliary handle

11 Indicator of power (Mod. H10,5/1200EV)

12 Greeze tank cover

EQUIPMENT

- Auxiliary handle

- Tube of grease

- Operating instructions with Safety instructions

- Warranty

BRIEF DESCRIPTION

The machine is intended for chiselling work in concrete,

brick, masonry and asphalt as well as for driving in and

compacting, when using the respective accessories.

BEFORE USING THIS TOOL

WARNING! Before carrying out any work, check, for

instance, using a metal detector, that there are no electric wires

or gas or water pipes under the surfaces you wish to work on.

Make sure the mains voltage is correct: it must be

the same as that on the specication label. Machines with

230V can also be connected to a 220V mains supply.

For mod. H10,5/1200EV. When connected to power

source, indicator of power is lighted.

WARNING! Always disconnect the plug from the

socket before doing any work on the machine.

1. Auxiliary Handle

Operate your machine only with the auxiliary handle

4. The auxiliary handle 4 can be set to any position for a

secure and low-fatigue working posture. Loosen the knurled

nut 10, rotate the auxiliary handle 4 around the axis of the
