machine to the required position and tighten the knurled

nut 10 again. The auxiliary handle 4 can be mounted to a

different position. For this, completely unscrew the knurled

nut 10 and then pull out the hexagon bolt upward. Pull

off the auxiliary handle 4 to the side and turn around the

remaining clamping element by 180°. Mount the auxiliary

handle 4 in reverse order.

2. Changing the Tool

WARNING! Before any work on the machine itself,

pull the mains plug.

With the SDS-max tool holder, simpler and easier tool

changing is possible without additional aids.

The dust protection cap 1 largely prevents the entry

of drilling dust into the tool holder during operation. When

inserting the tool, take care that the dust protection cap 1 is

not damaged.

A damaged dust protection cap should be changed

immediately. We recommend having this carried out by an

after-sales service.

Inserting

Clean and lightly grease the shank end of the tool.

Insert the tool in a twisting manner into the tool holder until

it latches itself. Check the loatching by pulling the tool.

Removing

Push back the locking sleeve 2 and remove the tool.

START UP

Switching On and Off

Mod. Н18/1500EV

To start the tool, rstly, push the On/Off switch to the

direction shown by the arrow “1” on the switch. Then push

the On/Off switch to the direction shown by the arrow “2” on

the switch. To stop the tool, push the On/Off switch to the

direction shown by the arrow “2” on the switch.

Mod. Н10,5/1200EV

To start the tool, push the On/Off switch to the “ON

(I)” position. To stop the tool, push the On/Off switch to the

“OFF (O)” position.

Setting the Impact Rate

The electronic control enables speed preselection in

accordance with the material to be worked. The constant

electronic control keeps the preselected impact rate nearly

constant between no-load and load conditions. Select

the impact rate with the thumbwheel 8 according to the

material. Refer to the table below for the relationship

between the number settings on the adjusting dial and the

blows per minute.

Thumbwheel

Position

Blows per minute, min

-1

Н18/1500EV Н10,5/1200EV

1 1000 2700

2 1180 2900

3 1360 3100

4 1540 3300

5 1720 3500

6 1900 3700

Changing the Chiselling Position

The chisel can be locked in 12 positions. In this

manner, the optimum working position can be set for each

application. Insert the chisel into the tool holder. Push the

chisel adjustment ring 3 forward and turn the chisel to the

required position with the chisel adjustment ring 3. Release

the chisel adjustment ring 3 and turn the chisel until it

latches.

OPERATING INSTRUCTIONS

Turn the tool on and apply slight pressure on the tool so

that the tool will not bounce around, uncontrolled. Pressing

very hard on the tool will not increase the efciency.

For low temperatures, the machine reaches the full

impact rate only after a certain time. This start-up time can

be shortened by striking the chisel in the machine against

the oor one time.

Sharpening Chisels

Good results are only achieved with sharp chisels;

therefore, sharpen the chiselling tools in good time. This

ensures a long service life of the tools and good working

performance.

NOISE AND VIBRATION

Hammers have mounted in the principal hand grip 7

damper 5 that reduses occuring vibrations.

This tool has been designed and made to reduce

noise to a minimum. However, in spite of this, in certain

circumstances the maximum noise level in the place

of work could exceed 85 dBA. In this case, the operator

should wear ear protection.

Use ear protection!

WARNING! The vibration level given in these

instructions has been measured in accordance with

a standardized measurement procedure specied in

EN60745 and can be used to compare devices. Different

uses of the device give rise to different vibration levels and

in many cases they may exceed the values given in these

instructions. It is easy to underestimate the vibration load

if the electrical power tool is used regularly in particular

circumstances.

Note. If you wish to make an accurate assessment of

the vibration loads experienced during a particular period of

working , you should also take into account the intervening

periods of time when the device is switched off or is running

but is not actually in use. This can result in a much lower

vibration load over the whole of the period of working.

ACCESSORIES

Accessories and their corresponding order number

can be found in our catalogues.

MAINTENANCE AND CARE

WARNING! Before any work on the machine itself,

pull the mains plug.

When you notice a decrease in hammer output, take

the machine to an Ofcial Service Centre.

A damaged dust protection cap should be changed

immediately. We recommend having this carried out by an

after-sales service.

Tool inspection: Using a worn tool will reduce the

efciency of the work being performed and could lead to

motor damage and the tools should be changed when any

abrasion is noted. Daily: Clean the tool holder.

Inspect the mounting screws: Regularly inspect all

the mounting screws and ensure they are rmly tightened.

Should any screw be loose, tighten it immediately. Failure

to do so could put you at serious risk.

Motor maintenance: Take the utmost care to ensure

that the motor winding is not damaged and does not
