TRION
15
GB
push base runner approx. 5 mm forwards,
set desired inclination according to the scale
[5-
2]
,
tighten locking screw
[4-1]
.
The base runner can be moved back for sawing
close to edges.
Remove chip guard and splinterguard,
release locking screw
[4-1]
with Allen key
[1-4]
,
push base runner to rear position so that the
centring pin
[5-1]
fits in the opening
[5-3]
,
tighten locking screw
[4-1]
.
7.7 Adjusting the pendulum stroke
In order to process different materials with an opti-
mum feed movement the pendulum jigsaws have
an adjustable pendulum stroke. Select the desired
setting with the pendulum stroke switch
[1-5]
:
setting 0 = pendulum stroke off
setting 3 = maximum pendulum stroke
7.8 Adjusting the number of strokes
PSB 300 Q,
PSB 300 EQ
You can regulate the number of strokes steplessly
between 1000 and 2900 min
-1
using the adjusting
wheel
[1-2; 2-3]
. This enables you to optimise the
cutting speed to suit the material.
8 Working with the machine
8.1 Free hand according to the scribe mark
The triangular shape of the splinterguard
[4-3]
shows the cutting line of the saw blade and thus fa-
cilitates cutting to a scribe mark.
8.2 Plunge cutting without pilot drilling
The base runner must be in the front position for
plunge cuts in timber materials (basic setting, see
Figure
[1]
).
Place saw on the front edge of the runner.
Set saw to maximum no. of strokes and pendu-
lum stroke setting 3 and start the plunge cut
into the workpiece (Figure
[6]
).
9 Service and maintenance
Customer service and repair
only
through manufacturer or service
workshops: Please find the nearest
address at: www.festool.com/service
Use only original Festool spare parts!
Order No. at: www.festool.com/service
Damaged safety devices and components must be
repaired or replaced in a recognised specialist
workshop, unless otherwise indicated in the oper-
ating manual.
To ensure constant air circulation, always keep the
cooling air openings in the motor housing clean and
free of any obstruction.
Recommended settings of the pendulum
stroke
Hard and soft wood,chip board, wood
fibre board
1 - 3
Wood core plywood, plywood, plastics 1 - 2
Ceramic 0
Aluminium, NF metals 0 - 2
Steel 0 - 1
Recommended number of strokes (adjusting
wheel setting)
Hard and soft wood, wood core plywood,
plywood, chip board
6
Wood fibre boards 4 - 6
Plastics 3 - 6
Ceramic, aluminium, NF metals 3 - 5
Steel 2 - 4
WARNING
Risk of injury
Always secure the workpiece in such a manner
that it cannot move while being machined.
WARNING
Risk of injury, electric shock
Always disconnect the mains plug from the
socket before performing maintenance work on
the machine!
All maintenance and repair work which requires
the motor housing to be opened must only be
carried out by an authorised service workshop.
EKAT
1
2
3
5
4
