14

T 15+3 Li, T 18+3 Li

GB

– Protect the battery pack from excessive heat > 50

°C or constant heat sources such as sunlight or

naked flames!

– Never use water to extinguish burning li-ion bat-

tery packs! Use sand or a fire blanket.

– Check the plug and the cable regularly and should

either become damaged, in order to avoid a haz-

ard, have them replaced by an authorised after-

sales service workshop.

– Always pull the mains plug out of the socket when

the charger is not in use.

2.4 Emission levels

Levels determined in accordance with EN 62841 are

typically:

Vibration emission value a

h

(vector sum for three di-

rections) and uncertainty K measured in accordance

with EN 60745:

Vibration emission value a

h

(vector sum for three di-

rections) and uncertainty K measured in accordance

with EN 60745:

The specified emission values (vibration, noise)

– are used to compare machines.

– They are also used for making preliminary esti-

mates regarding vibration and noise loads during

operation.

– They represent the primary applications of the

power tool.

Increase possible for other applications, with other

insertion tools or if not maintained adequately. Take

note of idling and downtimes of machine!

3 Intended use

Cordless drill suitable for

– drilling in metal, wood, plastic and similar materi-

als,

– inserting and tightening screws

– use with Festool batteries BPC and BPS of the

same voltage.

Charger TCL 3

suitable for

– charging Festool battery packs: BP, BPS and BPC

(NiMH, NiCd, li-ion are recognised automatically.)

– indoor use only.

The user is liable for improper or non-intend-

ed use; this also includes continuous industri-

al operation.

4 Technical data

* Speed specifications with fully charged battery pack.

** The maximum speed is reduced in the lower torque stages.

Sound pressure level L

PA

= 65 dB(A)

Sound power level L

WA

= 76 dB(A)

Uncertainty K = 3 dB

Wear ear protection.

Drilling in metal a

h

< 2,5 m/s

2

K = 1,5 m/s

2

Screwing a

h

< 2,5 m/s

2

K = 1,5 m/s

2

Cordless drill T 15+3 Li T 18+3 Li

Motor voltage 14,4 - 15,6 V 18 V

Idle engine speed* 1st gear 0 - 450 min

-1

2nd gear 0 - 1500 min

-1

Max. torque Soft material (wood) 27 Nm 35 Nm

Hard material (metal) 40 Nm 50 Nm

Adjustable torque** 1st gear 0,8 - 8 Nm 0,8 - 8 Nm

2nd gear 0,5 - 6 Nm 0,5 - 6 Nm

Chuck clamping range 1,5 - 13 mm

Drill diameter max. Wood 35 mm 45 mm

Metal 13 mm 13 mm

Tool holder in drill spindle 1/4 ’’ 1/4 ’’

Weight without battery pack with Centrotec 1,0 kg 1,0 kg
