Thermozone Portier

The efficiency of the air curtain(s) depends on the

air temperature and pressure differences across the

doorway and any wind forces.

NOTE! Negative pressure differential in buildings

considerably reduces the efficiency of the air

curtain, ventilation should therefore be balanced.

The airflow is set with the airflow selector so that

the air velocity is 3-4 m/s 1 m above the floor.

NOTE! When PS210E09 or PS215E14 is set on

high heat output, the fan speed is automatically

set to high. A baffle on each side of the doorway

will improve the efficiency of the air curtains.

Trouble shooting

If the fans stop, check the following:

a) Power supply; check fuses, safety cut-out and

time switch (if any) that starts and stops the unit.

b) That the airflow selector is correctly set. If the

error cannot be fixed, please contact qualified

service technician.

If there is no heat, check the following:

a) Power supply to electric heater; check fuses and

safety cut-out (if any).

b) Thermostat settings and actual temperature.

c) That the output selector (if any) is set correctly.

d) That the overheat protection has not been

released. If so, please check description on next

page.

Overheating

The Thermozone Portier is equipped with an

overheat protector. If it is released due to

overheating, reset as follows:

a) Disconnect the electric supply.

b) Investigate the problem and repair the fault.

c) Reset is performed as follows: Locate the red

button which is located inside the air curtain at

the inner gable to which the fan and the motor

are attached. It can be seen through the outlet

grille See fig. G. Press the button with at screw

driver until a click is heard.

d) Connect the air curtain again.

If the error cannot be fixed, please contact

qualified service technician.

Safety

Ensure that the area around the intake and

exhaust grille is kept free from objects which could

prevent the air to flow through the unit! During

operation the surfaces of the unit are hot! The unit

must never be covered fully or partially with

clothes, or similar which can cause risk of fire!

Maintenance

NOTE! Always disconnect the electricity prior to

cleaning or inspection (units with electric heat can

be supplied from more than one connection). The

fan motors and the other components require no

maintenance other than cleaning, once a year is

recommended. Grille, impeller and elements are

vacuum cleaned or cleaned with a damp cloth.

Open the front panel to reach elements and

impellers.

Earth leakage protection

If the installation is protected by a safety cutout,

which triggers when the appliance is connected, it

may be due to moisture inside the heating

elements. When an appliance containing a

heating element has not been used for a long

period of time and is stored in a damp

environment, moisture can enter the element. This

should not be seen as a fault, but is simply rectified

by connecting the appliance to the mains supply

via a socket without a safety cut-out, so that the

moisture can be vaporised out of the element. The

drying time can vary from a few hours to a few

days. As a preventive measure the air curtain

should occasionally be run for a short time.

The guarantee is only valid if the Thermozone

Portier units are used in the manner intended by

the manufacturer and in accordance with the

installation and maintenance instructions.
